Ball Valve

Ball Valve

Ball valves are available in bronze, brass, carbon steel or stainless steel materials. Select the right ball valve in one-piece, two-piece, three-piece, full port, or conventional port. A range of trim material is available. The right end connections to choose from include press-to-connect, threaded, solder or flanged.

Hard Seal Trunnion Mounted Ball valve

Hard Seal Trunnion Mounted Ball valve

Design and Manufacture: API 6D,API 608,ISO 17292,GB/T12237,GB/T19672
Size Range: 2”~48”
Pressure Ratings: 150LB-2500LB(PN1.6-PN42.0MPa)
Temperature Range: -196℃~650℃
End Connections: ASME B16.5 ,ASME B16.25,JB/T79,GB/T9113,HG/T20529,HG/T20615,EN1092,GB/T12224
Face to Face Dimension: ASME B16.10,GB/T12221,JB 1686, EN 588
Inspection and Testing: API 6D,API 598,JB/T9092,GB/T13927,GB/T26480


Soft Seal Trunnion Mounted Ball Valve

Soft Seal Trunnion Mounted Ball Valve

Design and Manufacture: API 6D,API 608,ISO 17292,GB/T12237,GB/T19672
Size Range: 2"~48"
Pressure Ratings: 150LB-2500LB(PN1.6-PN10.0MPa)
Temperature Range: -196℃~200℃
End Connections: ASME B16.5 ,ASME B16.25,JB/T79,GB/T9113,HG/T20529,HG/T20615,EN1092,GB/T12224
Face to Face Dimension: ASME B16.10,GB/T12221,JB 1686, EN 588
Inspection and Testing: API 6D,API 598,JB/T9092,GB/T13927,GB/T26480


Soft Seal Floating Ball Valve

Soft Seal Floating Ball Valve

Design and Manufacture: API 6D,API 608,ISO 17292,GB/T12237,GB/T1967
Size Range: 1/2"~10"
Pressure Ratings: 150LB-2500LB(PN1.6-PN42.0MPa)
Temperature Range: -196℃~200℃
End Connections: ASME B16.5 ,ASME B16.25,JB/T79,GB/T9113,HG/T20529,HG/T20615,EN1092,GB/T12224
Face to Face Dimension: ASME B16.10,GB/T12221,JB 1686, EN 588
Inspection and Testing: API 6D,API 598,JB/T9092,GB/T13927,GB/T26480


FS Soft Seal Floating Ball Valve

FS Soft Seal Floating Ball Valve

Design and Manufacture: API 6D,API 608,ISO 17292,GB/T12237,GB/T19672
Size Range: 1/2"~4"
Pressure Ratings: 150LB-900LB(PN1.6-PN15.0MPa)
Temperature Range: -196℃~200℃
End Connections: ASME B16.11, ASME B16.25, GB/T12224
Face to Face Dimension: Manufacturer standard
Inspection and Testing: API 6D,API 598,JB/T9092,GB/T13927,GB/T26480


Hard Seal-Floating Ball Valve

Hard Seal-Floating Ball Valve

Design and Manufacture: API 6D,API 608,ISO 17292,GB/T12237,GB/T19672
Size Range: 1/2"~10"
Pressure Ratings: 150LB-2500LB(PN1.6-PN42.0MPa)
Temperature Range: -196℃~650℃
End Connections: ASME B16.5 ,ASME B16.25,JB/T79,GB/T9113,HG/T20529,HG/T20615,EN1092,GB/T12224
Face to Face Dimension: ASME B16.10,GB/T12221,JB 1686, EN 588
Inspection and Testing: API 6D,API 598,JB/T9092,GB/T13927,GB/T26480


Full Welded Ball Valve

Full Welded Ball Valve

Design and Manufacture: API 6D,API 608,ISO 17292,GB/T12237,GB/T19672
Size Range: 2"~40"
Pressure Ratings: 150LB-2500LB(PN1.6-PN42.0MPa)
Temperature Range: -196℃~200℃
End Connections: ASME B16.5 ,ASME B16.25,JB/T79,GB/T9113,HG/T20529,HG/T20615,EN1092,GB/T12224
Face to Face Dimension: ASME B16.10,GB/T12221,JB 1686, EN 588
Inspection and Testing: API 6D,API 598,JB/T9092,GB/T13927,GB/T26480


Top Entry Ball Valve

Top Entry Ball Valve

Design and Manufacture: API 6D,API 608,ISO 17292,GB/T12237,GB/T19672
Size Range: 2"~10"
Pressure Ratings: 150LB-900LB(PN1.6-PN15.0MPa)
Temperature Range: -196℃~200℃
End Connections: ASME B16.5 ,ASME B16.25,JB/T79,GB/T9113,HG/T20529,HG/T20615,EN1092,GB/T12224
Face to Face Dimension: ASME B16.10,GB/T12221,JB 1686, EN 588
Inspection and Testing: API 6D,API 598,JB/T9092,GB/T13927,GB/T26480


Three Way&Four Way Ball Valve

Three Way&Four Way Ball Valve
Design and Manufacture: API 6D,API 608,ISO 17292,GB/T12237,GB/T19672
Size Range: 1/2"~8"
Pressure Ratings: 150LB(PN1.6-PN4.0MPa)
Temperature Range: -29℃~350℃
End Connections: ASME B16.5 , JB/T79,GB/T9113,HG/T20529,HG/T20615,EN1092
Face to Face Dimension: Manufacturer standard
Inspection and Testing: API 6D,API 598,JB/T9092,GB/T13927,GB/T26480


Flange High Temperature Ball Valve

Flange High Temperature Ball Valve
Design and Manufacture:API 6D,API 608,ISO 17292,GB/T12237,GB/T19672
Size Range: 1/2"~8"
Pressure Ratings: 150LB(PN1.6-PN2.5MPa)
Temperature Range: -196℃~300℃
End Connections: ASME B16.5 ,ASME B16.25,JB/T79,GB/T9113,HG/T20529,HG/T20615,EN1092,GB/T12224
Face to Face Dimension: ASME B16.10,GB/T12221,JB 1686, EN 588
Inspection and Testing: API 6D,API 598,JB/T9092,GB/T13927,GB/T26480


Thin Ball Valve

Thin Ball Valve

Design and Manufacture: API 6D,API 608,ISO 17292
Size Range: 1/2”~8”
Pressure Ratings: 150LB(PN1.6-PN2.5MPa)
Temperature Range: -196℃~350℃
End Connections: ASME B16.5 , EN1092
Face to Face Dimension: ASME B16.10, EN 588
Inspection and Testing: API 6D,API 598


Heating Ball Valve

Heating Ball Valve

Design and Manufacture: API 6D,API 608,ISO 17292,GB/T12237,GB/T19672
Size Range: 1/2"~10"
Pressure Ratings: 150LB-600LB(PN1.6-PN10.0MPa)
Temperature Range: -196℃~200℃
End Connections: ASME B16.5 ,ASME B16.25,JB/T79,GB/T9113,HG/T20529,HG/T20615,EN1092,GB/T12224
Face to Face Dimension: ASME B16.10,GB/T12221,JB 1686, EN 588
Inspection and Testing: API 6D,API 598,JB/T9092,GB/T13927,GB/T26480
